Specifications

• Processor TypeIntel
• Processor familyIntel® Xeon® Scalable 8100/8200 series Intel® Xeon® Scalable 6100/6200 series Intel® Xeon® Scalable 5100/5200 series Intel® Xeon® Scalable 4100/4200 series Intel® Xeon® Scalable 3100/3200 series
• Processor core available4 to 28 core, depending on model
• Processor cache8.25 – 38.50 MB L3, depending on processor model
• Maximum memory3.0 TB with 128 GB DDR4, depending on processor model; 6.0 TB with HPE 512GB 2666 Persistent Memory Kit, depending on processor model
• Memory slots24 DIMM slots
• Memory typeHPE DDR4 Smart Memory with optional Intel® Optane™ persistent memory 100 series for HPE, depending on processor model selected. Intel Optane Persistent Memory for HPE only supported on select 2nd Generation Intel Scalable Series Processors, to include: 82xx, 62xxR, 62xx, 52xxR, 52xx series processors, and the 4215R and 4215 processors.
• NVDIMM typeHPE NVDIMM-N *Only available on 1st Generation Intel® Xeon® Scalable Processors
• NVDIMM rankSingle rank
• NVDIMM capacity16 GB
• Drive supported8 or 12 LFF SAS/SATA/SSD 8, 10, 16, 18 or 24 SFF SAS/SATA/SSD; 2 M.2 SATA SSD standard on primary riser, depending on configuration; 6 SFF rear drive optional or 3 LFF rear drive optional and 2 SFF or 2 Dual UFF rear drive optional; 20 SFF NVMe optional; NVMe support via Express Bay will limit maximum drive capacity
• Infrastructure managementHPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download) (standard) HPE iLO Advanced, and HPE OneView Advanced (optional; requires licenses)
• System fan featuresHot-plug redundant fans, standard
• Expansion Slots8, for detailed descriptions reference the QuickSpecs
• Network ControllerHPE 1 Gb 331i Ethernet adapter 4-ports per controller and/or optional HPE FlexibleLOM, depending on model
• Storage controller1 HPE Smart Array S100i and/or 1 HPE Smart Array P408i-a and/or 1 HPE Smart Array P816i-a and/or 1 HPE Smart Array E208i-a, depending on model
• Processor number1 or 2
• Processor speed3.9 GHz, maximum depending on processor
• Memory, standard3.0 TB (24 X 128 GB) LRDIMM; 6.0 TB (12 X 512 GB) Persistent Memory
• SecurityOptional locking Bezel Kit, Intrusion Detection Kit, and HPE TPM 2.0
• Form Factor2U
• Weight32.6 lb
• Weight14.76 kg
• Minimum dimensions ( H x W x D)17.54 x 28.75 x 3.44 in
• Minimum dimensions ( H x W x D)44.55 x 73.03 x 8.74 cm

Features

• Defend applications and data before your server is built with the new HPE Trusted Supply Chain offering.
• Supporting additional second generation Intel® Xeon® Scalable processor family offerings.
• Increased Single-Width GPU Density with up to 7 NVIDIA Tesla T4 16GB Computational Accelerators or 7 Xilinx Alveo U50 Accelerators supported in a standard-depth 2U rack form factor
• Networking Choice (NC) server models provide greater flexibility in the primary networking selection.
• Intel® Optane™ persistent memory 100 series for HPE offers the flexibility to deploy as dense memory or fast storage and enables per-socket memory capacity of up to 3.0 TB.³
• iLO 5 security enhancements: Server Configuration Lock, iLO Security Dashboard and Workload Performance Advisor. HPE InfoSight provides cloud-based analytics to predict and prevent issues proactively.
