Products

• 48 10/100/1000Mbps RJ45 ports
• Innovative energy-efficient technology saves power consumption
• Supports MAC address self-learning and auto MDI/MDIX
• Standard 19-inch rack-mountable steel case

HARDWARE FEATURES

Standards And Protocols : IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x

Interface : 48 10/100/1000Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)

Network Media :

• 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
• 100BASE-TX/1000BASE-T: UTP category 5, 5e or above cable (maximum 100m)

Physical Security Lock : No

Power Supply : 100-240VAC, 50/60Hz

Dimensions (W x D x H) : 17.3 x 8.7 x 1.7 in. (440 x 220 x 44 mm)

Mounting : 19″ 1U Rack Mountable (Mounting bracket included)

Max Power Consumption : 32.3W

Max Heat Dissipation : 110.2BTU/h

PERFORMANCE

Switching Capacity : 96Gbps

Packet Forwarding Rate : 71.4Mpps

MAC Address Table : 16K

Buffer Memory : 12Mb

Jumbo Frame : 12KB

Transfer Method : Store-and-Forward
