Products

• AC1750 Dual Band Wi-Fi – Simultaneous 450Mbps on 2.4GHz + 1300Mbps on 5GHz
• Three Antennas – Three adjustable external antennas provide optimal Wi-Fi coverage and reliable connections
• Gigabit Ethernet port – Act as a wireless adapter to connect a wired device to your network at Gigabit speed
• Intelligent Signal Light – Help to find the best location for optimal Wi-Fi coverage by showing the signal strength
• AP Mode – Create a new Wi-Fi access point to enhance your wired network with Wi-Fi capability
• TP-Link Tether App – Easily access and manage your network using any iOS or Android mobile device
• Ultimate Compatibility – Extend the range of any Wi-Fi router or wireless access point

HARDWARE FEATURES

Plug Type : EU, UK, US, AU, KR, JP

Standards And Protocols : IEEE802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b

Interface : 1 x 10/100/1000M Ethernet Port (RJ45)

Ports : 1 Gigabit Ethernet Port

Button : WPS Button, Reset Button, LED Button, Power Button

Input Power : 100-240V~50/60Hz

Power Consumption : 10W (max power consumption)

Dimensions (W x D x H) : 6.4 x 3.0 x 2.6 in. (163 x 76.4 x 66.5mm)

Antenna : 3 x external

WIRELESS FEATURES

Wireless Standards : IEEE 802.11a/n/ac 5 GHz, IEEE 802.11b/g/n 2.4 GHz

Frequency : 2.4GHz & 5GHz(11ac)

Signal Rate :

• 5GHz:Up to 1300Mbps
• 2.4GHz:Up to 450Mpbs

Wireless Modes : Range Extender/Access Point

Wireless Functions :

• Wireless Statistic
• Concurrent Mode Boost Both 2.4G/5G WiFi Band
• Access Control
• LED Control
• Domain Login Function
• Wi-Fi Coverage

Wireless Security : 64/128-bit WEP, WPA-PSK / WPA2-PSK
