• Superior Extended Range – Four fixed external antennas extend Wi-Fi coverage*
• 4-Stream for AC2600 Dual Band Wi-Fi – Simultaneous 800Mbps on 2.4GHz + 1733Mbps on 5GHz
• 4×4 MU-MIMO** – Simultaneously transfers data to multiple devices for 4x faster performance
• Beamforming Technology – Send targeted Wi-Fi signal to individual devices for stronger connections
• Gigabit Ethernet Port – Provide faster wired connections to smart TVs, computers and gaming consoles
• Intelligent Signal Light – Helps to determine the best location for optimal Wi-Fi coverage by indicating the signal strength in the current placement
• AP Mode – create a new Wi-Fi access point to enhance your wired network with Wi-Fi capability
• TP-LINK Tether App – Easily access and manage your network using any iOS or Android mobile device
• Ultimate Compatibility – Extend the range of any Wi-Fi router or wireless access point***

HARDWARE FEATURES

Plug Type : US

Standards And Protocols : IEEE802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE 802.11a

Interface : 1x 10/100/1000M Ethernet Port (RJ45)

Ports : 1 Gigabit Ethernet Port

Button : WPS Button, Reset Button, LED Button, Power Button

Input Power : 100-240V~50/60Hz

Power Consumption : 12W（max power consumption）

Dimensions (W x D x H) : 6.4x 3.4 x 1.6 in. (163 x 86 x 40mm)

Antenna : 4x external

WIRELESS FEATURES

Wireless Standards : IEEE 802.11a/n/ac 5GHz, IEEE 802.11b/g/n 2.4GHz

Frequency : 2.4GHz & 5GHz(11ac)

Signal Rate :

• 5GHz:Up to 1733Mbps
• 2.4GHz:Up to 800Mpbs

Wireless Modes : Range Extender/Access Point

Wireless Functions :

• Wireless Statistic
• Concurrent Mode boost both 2.4G/5G WiFi band
• High Speed Mode for great speed for HD Gaming and video
• Access Control
• LED Control
• Domain Login Function

Wireless Security : 64/128-bit WEP, WPA-PSK / WPA2-PSK

WIRELESS

Working Modes : Range Extender/Access Point
