Products

• Integrated into Omada SDN: Centralized Cloud Management and Intelligent Monitoring.
• Centralized Management: Cloud access and Omada app for ultra convenience and easy management.*
• PoE Support: Supports Power over Ethernet (802.3af/at) for convenient deployment.
• Easy Installation: Simple mounting design for easy attachment to a wall or ceiling.
• Secure Guest Network: Along with multiple authentication options (SMS/Facebook Wi-Fi/ Voucher, etc.) and abundant wireless security technologies.*
• Load Balancing: Limit the number of users on each access point and remove devices with weak reception to keep your Wi-Fi running at peak performance.
• Scheduling: Automatically reboot the access point and turn on or off the Wi-Fi at the time you set.

Specifications

Hardware Features

Interface : 1× Fast Ethernet (RJ-45) Port (Support IEEE802.3af PoE)

Button : Reset

Power Supply : 802.3af PoE or external 9VDC/0.6A power supply

Power Consumption : 2.8 W

Dimension ( W x D x H ) : 7.5×6.8×1.2 in (189.4×172.3×29.5mm)

Antenna Type : Internal 2× 4 dBi Omni

Mounting : Ceiling /Wall Mounting (Kits included)

Wireless Features

Wireless Standards : IEEE 802.11n, IEEE 802.11g, IEEE 802.11b

Frequency : 2.4 GHz and 5 GHz

Signal Rate :

• 11n: Up to 300Mbps(dynamic)
• 11g: Up to 54Mbps(dynamic)
• 11b: Up to 11Mbps(dynamic)

Omada App : Yes
