• Fast Dual-Band Wi-Fi: Simultaneous 450 Mbps on 2.4 GHz and 1300 Mbps on 5 GHz totals 1750 Mbps Wi-Fi speeds.^†
• High-Density Connectivity: MU-MIMO, Load Balance, and professional antennas improve capacity in high-density environments to connect more devices simultaneously.
• Integrated into Omada SDN: Supports Centralized Cloud Management, and Intelligent Monitoring.
• Centralized Management: Cloud access and Omada app for ultra convenience and easy management.
• Seamless Roaming: Even video streams and voice calls are unaffected as users move between locations.*
• PoE Support: Supports both standard 802.3af/at and Passive PoE (PoE adapter included) for flexible installations.
• Secure Guest Network: Along with multiple authentication options (SMS/Facebook Wi-Fi/ Voucher, etc.) and abundant wireless security technologies.*

Specifications

Hardware Features

Interface : 2 × Gigabit Ethernet (RJ-45) Port (One port supports IEEE802.3af/at PoE and Passive PoE)

Physical Security Lock : Yes

Button : Reset

Power Supply : 802.3af/at PoE
48V Passive PoE (+4,5pins; -7,8pins. PoE Adapter Included)

Power Consumption : 12.3 W

Dimension ( W x D x H ) : 8.1 × 7.1 × 1.5 in (205.5 × 181.5 × 37.1 mm)

Antenna Type : Internal Omni
• 2.4 GHz: 3× 3.5 dBi
• 5 GHz: 3× 4 dBi

Mounting : Ceiling /Wall Mounting (Kits included)

Wireless Features

Wireless Standards : IEEE 802.11ac/n/g/b/a

Frequency : 2.4 GHz and 5 GHz

Signal Rate : 5 GHz: Up to 1300 Mbps
2.4 GHz: Up to 450 Mbps

Omada App : Yes
