Products

• Fast Dual-Band Wi-Fi: Simultaneous 450 Mbps on 2.4 GHz^△ and 867 Mbps on 5 GHz totals 1317 Mbps Wi-Fi speeds.^†
• Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)^‡, Centralized Cloud Management, and Intelligent Monitoring.
• Centralized Management: Cloud access and Omada app for ultra convenience and easy management.
• Seamless Roaming: Even video streams and voice calls are unaffected as users move between locations.*
• PoE Support: Support both standard 802.3af/at and Passive PoE (PoE adapter included)^△ for flexible installations.
• Secure Guest Network: Along with multiple authentication options (SMS/Facebook Wi-Fi/ Voucher, etc.) and abundant wireless security technologies.
• Advanced Wireless Tech: Optimize network performance with MU-MIMO, Band Steering, Airtime Fairness and Beamforming technologies.^△

Specifications

Hardware Features

Interface : Gigabit Ethernet (RJ-45) Port×1 (Support IEEE802.3af PoE and Passive PoE)

Physical Security Lock : Yes

Button : Reset

Power Supply : 802.3af/at PoE
24V Passive PoE (+4,5pins; -7,8pins. PoE Adapter Included)

Power Consumption : EU: 10.5 W
US: 12.6 W

Dimension ( W x D x H ) : 8.1 × 7.1 × 1.5 in (205.5 × 181.5 × 37.1 mm)

Antenna Type : 3 Internal Omni

2.4 GHz: 4 dBi
5 GHz: 5 dBi

Mounting : Ceiling /Wall Mounting (Kits included)

Wireless Features

Wireless Standards : IEEE 802.11ac/n/g/b/a

Frequency : 2.4 GHz and 5 GHz

Signal Rate :  5 GHz:Up to 867 Mbps
2.4 GHz:Up to 450 Mbps

Omada App : Yes
