• Speedy Wi-Fi – Superb wireless experience with 300Mbps (2.4GHz) + 867Mbps (5GHz) dual band Wi-Fi connections
• Superior Range – Three fixed antennas provide stable wireless connections and optimal coverage
• Versatile Connectivity – Fully compatible with the VDSL2/ADSL2+/ADSL2/ADSL standards, as well as fiber, cable and 3G/4G Internet services
• Beamforming Technology – Improves wireless range and performance at 5GHz band
• USB Port – Supports storage and print service sharing, FTP and media servers as well as 3G/4G dongle
• Tether App – TP-LINK Tether provides the easiest way to access and manage the router on your iOS and Android devices

HARDWARE FEATURES

Interface :

• 3 10/100 RJ45 LAN Ports
• 1 10/100/1000 RJ45 LAN/WAN Port
• 1 RJ11 Port
• 1 USB 2.0 Port

Button :

• WPS Button
• Wireless On/Off Button
• Power On/Off Button
• Reset Button

Power Supply : 12V/1.5A

IEEE Standards :

• IEEE 802.3
• IEEE 802.3u
• 802.3ab

VDSL2 Standards :

• ITU G.993.2, Up to 17a prole (POTS)
• ITU-T G.993.5 (G.vector)
• ITU-T G.998.4 (G.INP)

ADSL Standards :

• Full-rate ANSI T1.413 Issue 2,
• ITU-T G.992.1(G.DMT),
• ITU-T G.992.2(G.Lite),
• ITU-T G.994.1 (G.hs),
• ITU-T G.995.1

ADSL2 Standards :

• ITU-T G.992.3 (G.DMT.bis),
• ITU-T G.992.4 (G.lite.bis)

ADSL2+ Standards : ITU-T G.992.5

Dimensions (W x D x H) : 243.5×167.5×32.7mm

Antenna Type : 3 fixed external antennas

WIRELESS FEATURES

Wireless Standards

• IEEE 802.11a/n/ac 5GHz,
• IEEE 802.11b/g/n 2.4GHz

Wireless Speeds :

• 867Mbps at 5GHz
• 300Mbps at 2.4GHz

Wireless Functions :

• Enable/Disable Wireless Radio
• WDS Bridge
• WMM
• Wireless Statistics

Wireless Security :

• 64/128-bit WEP
• WPA/WPA2
• WPA-PSK/WPA-PSK2 encryptions
• Wireless MAC Filtering

Wireless Schdule : Support 2.4GHz and 5GHz Wireless Schedule

SOFTWARE FEATURES

Quality of Services : ATM QoS, Bandwidth Control

Security : NAT Firewall, Access Control, IP and MAC Address Binding

Operating Modes : VDSL/ADSL Modem Router, Wireless Router,3G/4G Router

Management :

• Web Based Conguration(HTTP)
• Remote management
• command Line Interface
• SSL for TR-069
• SNMP v1/2c
• Web Based Firmware Upgrade
• Diagnostic Tools

DHCP : Server, Client, DHCP Client List, Address Reservation, DHCP Relay

Port Forwarding : Virtual Server, Port Triggering, DMZ, ALG, UPnP

Dynamic DNS : DynDns, NO-IP

VPN Pass-Through : PPTP, L2TP, IPSec Passthrough

Protocols : Supports IPv4 and IPv6

ATM/PPP Protocols :

• ATM Forum UNI3.1/4.0
• PPP over ATM (RFC 2364)
• PPP over Ethernet (RFC2516)
• IPoA (RFC1577/2225)
• MERIPoE (RFC 1483 Routed)
• Bridge (RFC1483 Bridge)
• PVC – Up to 8 PVCs

Advanced Functions :

• Parental Control
• Network Address Translation(NAT)
• Port Mapping(Grouping)
• Static Routing
• DNS Relay
• DDNS
• IGMP V1/V2/V3

USB Sharing : Support Samba(Storage)/FTP Server/Media Server/Printer Server, 3G/4G Modem

Guest Network : 2.4GHz guest network, 5GHz guest network

IPSec VPN : Supports up to 10 IPSec VPN tunnels

Beamforming : 5GHz
