Ubiquiti UniFi Switch USW-FLEX Key Features

• Auto-sensing 802.3af PoE
• 5 RJ45 Gigabit Ethernet ports
• Switching Performance
• PoE Flexibility
• Indoor/Outdoor Design
• Versitile Mounting
• Seamless Integration

Versatile Mounting

The USW-Flex can be installed horizontally or vertically making it ideal for desktop, magnetic wall-mount, and pole-mount installations.

Indoor/Outdoor Design

The USW-Flex is designed for indoor or outdoor use. With its weatherproof housing and versatile mounting options, the USW-Flex provides both flexibility and durability for environments with extreme temperature variations.

Technical Specifications

General

• Dimensions: 122.5 x 107.1 x 28.0 mm (4.82 x 4.22 x 1.10″)
• Weight: 230 g (8.11 oz)
• Networking Interfaces: (5) 10/100/1000 Mbps RJ45 Ports
• Management Interface: Ethernet In-Band
• Power Method (Port 1):
  – PoE Mode 1: 802.3af/at (Pins 1, 2+; 3, 6-)1
  – PoE Mode 2: 802.3bt (Pins 1, 2+; 3, 6- and 4, 5+; 7, 8-)2
  – PoE Mode 3: 50V/60W PoE Adapter3
• PoE Out (Ports 2-5): 802.3af (Pins 1, 2+; 3, 6-)
• Max. Power Consumption (Excluding PoE Output): 5W
• Max PoE Wattage Per Port: 15.4W
• Total PoE Power Budget:
  – Powered by AF mode PSE: 8W
  – Powered by AT mode PSE: 20W
  – Powered by BT mode PSE: 46W
  – Powered by PoE Adapter (Enabled in Controller): 46W
• Voltage Range:
  – 802.3af: 44 – 57V
  – 802.3at/bt: 50 – 57V
• LEDs:
  – System: Status
  – RJ45 Data Ports: PoE; Link/Speed/Activity
• ESD/EMP Protection: ± 16kV Air, ± 16kV Contact
• Operating Temperature:
  – 46W PoE Output: -40 to 55° C (-40 to 131° F)
  – 25W PoE Output: -40 to 65° C (-40 to 149° F)
• Operating Humidity: 5 to 95% Noncondensing

1 Recommended PoE power source: US-8-150W (sold separately)
2 Recommended PoE power source: USW-Industrial (sold separately)
3 Recommended PoE power source: POE-50-60W-WH (sold separately)
(POE-50-60W-WH requires enabling injector mode in UniFi Controller)
