Ubiquiti UniFi Video Camera G3 Dome – UVC-G3-Dome Features

• 1080p Full HD, 30 FPS
• EFL 2.8 mm, ƒ/2.0
• Wide-Angle Lens
• 802.3af PoE or 24V Passive PoE
• Built-in Microphone
• Wall or Ceiling Mount

Power Software Management

Use the UniFi Video mobile app for easy camera management and live streaming from an iOS or Android-based smartphone or tablet. The UniFi Video mobile app is now available in the App Store for iOS and Google Play Store for Android.

HD Image Quality

Featuring a wide-angle lens for a superior field of view, the UniFi Video Camera G3 Dome provides 1080p HD resolution at 30 FPS

Technical Specifications

UVC-G3-DOME Specifications

• Dimensions: Ø 132 x 60 mm (Ø 5.20 x 2.36″)
• Weight: 260 g (9.17 oz) x 5
• Networking Interface: (1) 10/100 Ethernet Port
• Sensor: 1/3″ 4-Megapixel HDR Sensor
• Lens: EFL 2.8 mm, ƒ/2.0
• Night Mode: IR LEDs with Mechanical IR Cut Filter
• Microphone: Yes
• Button: Factory Reset Button
• Power Method: 802.3af PoE or 24V Passive PoE
• Power Supply: 802.3af PoE Switch or 24V, 0.5A PoE Adapter (Included with Single-Pack)
• Maximum Power Consumption: 4W
• Mounting: Wall/Ceiling/Table
• Operating Temperature: -30 to 70° C (-22 to 158° F)
• Operating Humidity 20 – 90% Noncondensing

Video

• Video Compression: H.264
• Resolution: 1080p Full HD (1920×1080)
• Maximum Frame Rate: 30 FPS
• Image Settings: Brightness, Contrast, Sharpness, Saturation, Noise Reduction, 50/60 Hz

Other

• Viewing Angle:
  – Before Lens Correction: 100.4° (H), 59.1° (V), 117.3° (D)
  – After Lens Correction: 87.8° (H), 55.4° (V), 96.4° (D)
• Supported UniFi Video Version: UniFi Video 3.2 (or Newer)
• UniFi Video System Requirements: 64-bit Microsoft Windows 10/8/7, Ubuntu 14.04 or 16.04, or Debian 7.0 System with an Intel or Compatible 1.86 GHz (or Above) Processor and a Minimum of 4 GB RAM
